Design Notes

Capacity of connection is controlled by shear capacity of dowel-type fasteners and tube connector.
Connectors may have tight construction tolerance.
Refer to the CLT Handbook, U.S. Edition for additional information.

Panels Connect with Tube Connectors

Adjacent floor panels are butted together and secured using slotted steel tube and glued-in threaded rods.
