Panel Bears on Ledger at Wall

Panel bears on wood ledger and is connected with partially threaded screws. Ledger is attached to wall with post-installed anchors.

Purpose: Transfer of vertical loads from roof or floor panel to wall. Can also transfer in-plane loads between the wall and roof or floor panel.

Design Notes

  • Capacity of connection is dependent on capacity of anchor securing ledger to wall through dowel bearing.
  • Screws provide load path for in-plane loads.
  • Elevation control of ledger is critical.
Class
Class 2
Load
Load High
Cost
Cost $$
Const.
Constructability Easy
Fire
Fire Rating II

Panel Bears on Ledger at Wall

Panel bears on wood ledger and is connected with partially threaded screws. Ledger is attached to wall with post-installed anchors.
02.D - Panel Bears on Ledger at Wall
