Design Notes

Load is transferred through perpendicular to grain bearing.
Proprietary options exist. Possible suppliers include Simpson Strong-Tie.
Deck not shown for clarity. Beam may require bracing for lateral-torsional buckling.

Beam Splice with Steel Plate Scarf Joint

Wood beam is connected to a supported wood beam with a top-mounted steel connector.
