Panel Bears on Bracket at Wall

Panel bears on custom-fabricated connector with positive attachment between panel and connector using partially-threaded screws. Steel connector is attached to wall with post-installed anchors or embeds.

Purpose: Transfer of gravity loads from roof or floor panel to wall. Can also transfer in-plane loads between the wall and roof or floor panel.

Design Notes

  • Capacity of connection is dependent on perpendicular-to-grain capacity of panel and shear and tensile capacity of wall connector.
  • Consider eccentricity of panel bearing on connector.
  • Connection should accommodate different expected tolerance between concrete construction and timber construction.
  • Connection may be required to transfer out-of-plane wall loads into diaphragm.
  • Bracket may be added to top of panel where additional in-plane load transfer is required.
  • Inspectability is difficult if lower bracket is upturned at panel edge.
Class
Class 2
Load
Load Low
Cost
Cost $$
Const.
Constructability Moderate
Fire
Fire Rating III

Panel Bears on Bracket at Wall

Panel bears on custom-fabricated connector with positive attachment between panel and connector using partially-threaded screws. Steel connector is attached to wall with post-installed anchors or embeds.
02.D - Panel Bears on Bracket at Wall
