Panel Bears on Bracket at Wall with Collector Plate
Steel collector plate is connected to top of roof or floor panel with partially-threaded screws. Steel collector plate is welded to embed.
Panel Bears on Bracket at Wall with Collector Plate
Steel collector plate is connected to top of roof or floor panel with partially-threaded screws. Steel collector plate is welded to embed.
Purpose: Transfer of diaphragm forces from roof or floor panel to vertical lateral force-resisting system.
Design Notes
- Capacity of connection in the mass timber components is dependent on the screwed connection between the collector plate and panel or diaphragm capacity of the panel.
- A bolted connection to the embed may be preferred to avoid complications associated with welding adjacent to mass timber panels.
- Refer to other details in this table for gravity load transfer along length of panel to concrete connection.
- Class
- Class 2
- Load
- Load Low
- Cost
- Cost $$
- Const.
- Constructability Moderate
- Fire
- Fire Rating III
