1-Hour STC 58 I-Joist Floor Assembly (LWC Topping)

1-hour floor/ceiling assembly with I-joist floor framing, lightweight concrete topping, carpet, and resilient channels. Fire rating per UL L518; STC 58 and IIC 54 per National Evaluation Service Report NER-200.2-hour metal stud fire wall assembly per GA WP 1548 with wood stud bearing walls on either side. Option for wood structural panel sheathing.

1-Hour STC 58 I-Joist Floor Assembly (LWC Topping)

1-hour floor/ceiling assembly with I-joist floor framing, lightweight concrete topping, carpet, and resilient channels. Fire rating per UL L518; STC 58 and IIC 54 per National Evaluation Service Report NER-200.

AF14-1HourSTC58FloorIJoistLWC
