Panel Bears with Sill Plate
Panel bears on pressure treated sill plate. Plate is connected to panel with toenails and to concrete with cast-in or post-installed anchor bolts. Grout is provided below plate for elevation control.
Panel Bears with Sill Plate
Panel bears on pressure treated sill plate. Plate is connected to panel with toenails and to concrete with cast-in or post-installed anchor bolts. Grout is provided below plate for elevation control.
Purpose: Transfer of vertical load from panel to concrete.
Design Notes
- Capacity of connection is dependent on the perpendicular to grain capacity of plate.
- Bracket or side plate may be provided for transfer of in-plane and out-of-plane loads between panel and concrete.
- Connection may be installed without grout. Without grout, the connection does not accommodate likely variations in top of concrete elevations, even within the range of appropriate concrete tolerances.
- Class
- Class 1
- Load
- Load High
- Cost
- Cost $
- Const.
- Constructability Easy
- Fire
- Fire Rating II
