Beam Bears on Top of Wood Column with Angle

Beam is welded to angle with stiffener that knifes into column. Angle bears on column and is positively connected to column with partially threaded screws.

Purpose: Transfer of vertical load from steel beam to mass timber column.

Design Notes

Capacity of the connection is dependent on parallel-to-grain capacity of the column at angle.
Column may be routed at angle for flush finish.

Class: Class 2
Load: Load Medium
Cost: Cost $$
Const.: Constructability Easy
Fire: Fire Rating III

Beam Bears on Top of Wood Column with Angle

Beam is welded to angle with stiffener that knifes into column. Angle bears on column and is positively connected to column with partially threaded screws.
